UVA-LED Exposure Machine

UVA-LED flexo plate exposure machine, relying on UVA-LED light sources with concentrated wavelengths (peak wavelength 365nm), achieve efficient, environmentally friendly, and precise exposure effects in the flexographic plate making process, satisfying the needs of modern printing for high-quality plates and green production. Specific advantages are as follows:   Low Energy Consumption and Long Service Life：The electro-optical conversion efficiency of UVA-LED light sources reaches over 30%, reducing energy consumption by 50%-65% compared with traditional mercury lamp exposers; the service life of LED beads is as long as 10,000-20,000 hours, 5-6 times that of mercury lamps, which reduces the frequency of light source replacement and lowers long-term consumable costs.   High Expos...

The Scan-type UVA-LED beads Flexo Plate Exposure Machine BW-5280 delivers high-precision UV exposure for both digital and conventional flexographic printing plates. Featuring up to 3,630 high-power LED beads with energy output from 20-500mW/cm² and uniformity of ±3%, it ensures consistent exposure quality across the entire plate surface — even for large-format 50"×80" plates, exposure completes within 10 minutes. Equipped with a self-developed LED control system, independent UV radiation calibration, temperature-controllable design, and intelligent programming with preset mainstream plate-making parameters, this machine delivers professional-grade plate-making performance with minimal operator intervention. Double-sided automa...
